17D High Speed Medium Copper Wire Drawing Machine Gear Transmission

Brand Name : JD

Model Number : 17D

Certification : ISO9001

Place of Origin : China

MOQ : 1Set

Price : USD 10000-20000/Set

Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram

Supply Ability : 30 Sets/Month

Delivery Time : In 40-50 days after received your advanced payment

Packaging Details : Export packing the end of the sleepers fixed machinery to do non-slip, with bubble wrap anti-collision, external plastic packaging waterproof moisture

Materials : Copper Rod

Inlet wire Dia : 2.5mm-3.5mm

Outlet wire Dia : 0.4mm-1.6mm

Drawing number : 17

Max drawing speed : 1800m/min

Warranty : One year

Factory history : Specialized in this field for over 15 years

Our aim : Make clients the least invest,the highest returns

Usage : Produce wire cable

After-sales Service : Engineers available to service machinery overseas

Contact Now

17D High Speed Medium Copper Wire Drawing Machine Gear Transmission

1.Usage

The machine is used for drawing copper wire from 2.5mm-3.5mm to 0.4-1.6mm.

2.Main features of our product:

1. Manufacturer(developing history more than 15 years)

2. ISO approving,ISO9001-2008

3. Best after sale service(one year warranty,longtime maintenance,supply all the spare parts)

4. Advanced technique

5. We can design the machine that meet your requirements

Structure: the drawing equipment consists of main reduction box, die casing, wheel frame, wire brace

and electeical control system. The drawing blocks are verticaly fixed in sealed box body

Product Information

Technique Parameter :

Machine model	JDT--250A—17D	JDT—250B—17D	JDT—250B—17D
lnlet dia.(mm)	Φ2.60—Φ3.50	Φ2.60—Φ3.50	Φ2.60—Φ3.50
Outlet dia(mm)	Φ0.40—Φ1.20	Φ0.40—Φ1.60	Φ0.40—Φ2.00
Drawing die number	17	17	17
Main motor(KW)	37	55	55
Cone number	4
Cone material	coated by tungsten carbide
Max drawing speed	2000m/min
Take up machine motor	11kw
Spooler diameter	Φ500/Φ630
Transmission type	grinding gear of high precision
Body Structure	Iron casted
Annealing Structure	vertical or horizontal type (as your request)
Max annealing voltage	60V(DC)	60V(DC)	60V(DC)
Max annealing currency	2000A(DC)	2000A(DC)	2000A(DC)
Brake type	pneumatic	pneumatic	pneumatic
Take-up(optional)	Coiler machine single take up machine or double take up machine as you choose

Main Features:

The drawing machine body is iron casted, transmit by helical gear of high precision.

Drawing capstan is coated by tungsten carbide.

3-step DC annealing equipments.

PLC control wholly, mechanical speed synchronise with electrical speed.

Small footprint, easy to operate.

Product Pictures

17D High Speed Medium Copper Wire Drawing Machine Gear Transmission

3.Packaging & Shipping

17D High Speed Medium Copper Wire Drawing Machine Gear Transmission

4.Product Process

17D High Speed Medium Copper Wire Drawing Machine Gear Transmission

5.Our Factory

Long history

We have 15 years manufacturer history, companying with good reputation, since our factory set up in 2003.

Supply ability:

We specialize in design machines according customers' requirements. 300 sets of machines can be supplied/month.

Equipment working site:

You are welcomed to visit our factory, the machines can be operated on site, and you will master the usage of machines nearby.

Successful experience / Markets:

Be up to the international level. Our lines and related complete equipment have been exported to India,

Indonesia, Morocco, South Africa, Algeria,Mexcio,Russia ,Uzbekistan,bangladesh etc.

17D High Speed Medium Copper Wire Drawing Machine Gear Transmission

6.Engineers for machine’s installation and debugging in Uzbekistan

17D High Speed Medium Copper Wire Drawing Machine Gear Transmission

7.The Exhibition

17D High Speed Medium Copper Wire Drawing Machine Gear Transmission

8.Advantages:

1).XINDACHANG(JINDA )has some world famous parts suppliers. Have high price performance ratio.

2).special lubrication system for the gears and bearing.

3).second section annealing system, outside electrically neutral (no current flow to other unit)

4).body and other key components and parts are produced by our own factory, quality is reliable.

5) Our company’s developing process in more than 10 years.

9. After-sale service:

Pre-sale training:

In order to guarantee the customers are able fully to operate the machine, if the customer need, we can help customer training, includes:

(1) Correct operating mode

(2) Correct maintenance way

(3) Removable simple problem our company for our machine product,

Since the shipment date, our company free after sale maintenance service guarantee period is:

A: 1 year for mechanical part,

B: 6 month for electrical part.

Main Product:

Cable making equipment

v Wire drawing machine (multiple wire)

v Rod breakdown machine

v Tin-coating machine Rigid frame stranding machine

v Annealing machine

v Copper, Aluminum, Aluminum Alloy, Brass, Wire drawing machine

v Wire and cable production line
